PT3 Pump

PT3 Fuel Tank cpl. Diagram

Exploded parts diagram of the Fuel Tank cpl. of a Wacker Neuson PT3, with numbered balloons
Hover a box for the part, its price and its row below. Click it to select.
  • 105000156613
    $437.33
    TANK-FUEL,ASSEMBLY - 5000156613×1
  • 305200013319Not stocked
    Cap×1
  • 405000053660
    $8.13
    FILTER-ENGINE FUEL - 5000053660×1
  • 485200013320Not stocked
    Banjo fitting×1
  • 605000075270
    $1.85
    NUT-FLANGE - 5000075270×2
  • 635000156616
    $2.86
    BOLT-FLANGE - 5000156616×2
  • 705000210095
    $21.66
    FUEL LINE COMPLETE - 5000210095×1
  • 805200013321Not stocked
    Rubber pipe×1
  • 905200013322Not stocked
    Hose clamp×2
  • 2245000156533
    $13.79
    LEVER-CHOKE,COMPLETE - 5000156533×1
