PV 35A HAND-HELD GAS VIBRATOR
PV35A Transmission cpl. Diagram
- TRANSMISSION - 5000183832×1
- HOUSING,CLUTCH - 5000182984×1
- BEARING - 5000174823×2
- BEARING - 5000174801×4
- RING-RETAINING - 5000174802×2
- SHAFT-DRIVE - 5000174436×2
- HOUSING-FRONT - 5000183833×1
- GEAR,12 TOOTH - 5000180536×1
- GEAR,18 TOOTH - 5000180537×1
- GEAR,COMBINED 12T/18T - 5000183044×1
- BOLT M6 X 10 - 5000174439×2
- PIN-DOWEL - 5000174443×3
- BOLT M6 X 35 - 5000174444×4
- WASHER-LOCK M6 - 5000174804×4
- Gasket - 5000182692×1
- COUPLER - 5000174479×1
- Washer - 5000174455×1
- Spacer - 5000174456×1
- NUT-LOCK - 5000174453×1
