Rebar Cutter RCE-25/230
RCE-25/230 Reinforcement Cutting Equipment Diagram
- BLADE-CUTTING - 5000216979×1
- Cutter head - 5000216890×1
- SCREW-CAP,HEX HD. - 5000217039×1
- NUT-HEX HD. - 5000217025×1
- GASKET - 5000216936×1
- SPRING-COMPRESSION - 5000216854×1
- Piston cpl. - 5000216975×1
- Gasket - 5000216937×1
- O-Ring - 5000216931×1
- Screw - 5000216882×1
- WASHER-COPPER - 5000217048×1
- Cylinder assembly cpl. - 5000216978×1
- pressure relief - 5000216993×1
- O-Ring - 5000216922×1
- O-Ring - 5000216917×3
- kit-pump - 5000217009×1
- Protection - 5000227714×1
- BLADE-CUTTING - 5000216980×1
- CAP-FUEL TANK - 5000216856×1
- SPRING-COMPRESSION - 5000216863×1
- Washer - 5000216900×1
- Diaphragm - 5000216935×1
- HOUSING-PUMP - 5000216855×1
- RING-SEAL - 5000217033×1
- PLUG-SCREW - 5000217008×1
- SEAL-OIL - 5000217014×1
- BEARING-BALL - 5000217013×1
- 285000217074Not stockedRotor cpl.×1
- Screw - 5000217044×2
- SCREW-CHEESE HD. - 5000217020×2
- WASHER-LOCK,TOOTHED - 5000217034×2
- 325000216956Not stockedStator×1
- BEARING-BALL - 5000217012×1
- RING-COMPENSATING - 5000217032×2
- HOUSING-MOTOR - 5000216949×1
- WASHER-LOCK - 5000216912×2
- NUT-HEXAGON - 5000216843×2
- HOLDER-BRUSH - 5000217000×1
- BRUSH-CARBON - 5000216914×1
- Cover cpl. - 5000217001×1
- SWITCH-PRESS - 5000216958×1
- FILTER-INTERFERENCE - 5000216953×1
- Strain relief - 5000216918×1
- Screw - 5000217018×2
- SCREW-CAP,HEX HD. - 5000217022×4
- Washer - 5000217031×4
- WASHER-LOCK - 5000217035×4
- SCREW-CHEESE HD. - 5000217016×4
- HANDLE COMPLETE - 5000216977×1
- Screw - 5000217021×4
- BUSHING-CABLE - 5000216919×1
- 525000216955Not stockedPower supply cable with plug 230V×1
- set of screws RCE 25 - 5100000038×1
