Rebar Cutter RCP-25/230
RCP-25/230 Reinforcement Cutting Equipment Diagram
- Cutter head - 5000216966×1
- SET-FIXING - 5000217007×1
- SCREW-CHEESE HD. - 5000216835×1
- GASKET - 5000216936×1
- O-Ring - 5000216944×1
- Support - 5000216895×1
- WASHER-COPPER - 5000217048×1
- Screw - 5000216882×1
- SPRING-COMPRESSION - 5000216854×1
- Piston cpl. - 5000216985×1
- GASKET - 5000216950×1
- Cylinder assembly cpl. - 5000216986×1
- SCREW-CHEESE HD. - 5000216891×1
- pressure relief - 5000216994×1
- Lever cpl. - 5000216995×1
- O-Ring - 5000216930×1
- O-Ring - 5000216917×3
- O-Ring - 5000216933×3
- kit-pump - 5000217009×1
- SEAL-OIL - 5000217014×1
- HOUSING-PUMP - 5000216904×1
- Seal - 5000227719×1
- Screw - 5000227720×1
- Support - 5000216903×1
- Diaphragm - 5000216951×1
- CAP-FUEL TANK - 5000216905×1
- RING-SEAL - 5000217033×1
- PLUG-SCREW - 5000217006×1
- BEARING-BALL - 5000217013×1
- SCREW-CHEESE HD. - 5000216840×3
- 315000217073Not stockedRotor cpl.×1
- BEARING-BALL - 5000217012×1
- RING-COMPENSATING - 5000217032×4
- 345000216954Not stockedStator×1
- WASHER-LOCK,TOOTHED - 5000217034×2
- NUT-HEXAGON - 5000216843×2
- SCREW-CHEESE HD. - 5000216848×1
- WASHER-LOC - 5000217029×4
- Screw - 5000217045×4
- HOLDER-BRUSH - 5000216999×2
- BRUSH-CARBON - 5000216914×2
- Cover cpl. - 5000216981×2
- WASHER-LOCK - 5000216912×2
- SCREW-CHEESE HD. - 5000216858×2
- 455000217056Not stockedNameplate×1
- 465000217019Not stockedRivet×4
- SWITCH-PRESS - 5000216952×1
- Washer - 5000216847×2
- Screw - 5000217017×2
- Strain relief - 5000216918×1
- Screw - 5000217018×2
- FILTER-INTERFERENCE - 5000216953×1
- HANDLE COMPLETE - 5000216998×1
- Screw - 5000217046×2
- Screw - 5000217030×2
- BUSHING-CABLE - 5000216919×1
- 575000216955Not stockedPower supply cable with plug 230V×1
