RD24-100c DPF

RD24-100CDPF scraper Diagram

Exploded parts diagram of the scraper of a Wacker Neuson RD24-100CDPF, with numbered balloons — Hover a box for the part, its price and its row below. Click it to select.

15100013203
$3,432.45
Scraper - 5100013203×1
25100012984
$311.58
Cover - 5100012984×1
35100013402
$1.57
Countersunk screw - 5100013402×4
45100012965
$3.01
Locking washer - 5100012965×4
55100012545
$1.57
Hexagon nut - 5100012545×4
65100011630
$43.91
Hinge - 5100011630×2
75100012890
$1.57
Countersunk screw - 5100012890×4
105100012439
$9.78
Rubber piece - 5100012439×1
115100012610
$1.57
Hexagon screw - 5100012610×1
125100012965
$3.01
Locking washer - 5100012965×1
135100012545
$1.57
Hexagon nut - 5100012545×1
155100012932
$44.61
Handle - 5100012932×1
165100012600
$1.57
Hexagon screw - 5100012600×2
175100012965
$3.01
Locking washer - 5100012965×2
185100012545
$1.57
Hexagon nut - 5100012545×2
195100034807
$2.44
hexagon screw - 5100034807×2
215100013577
$1.57
Washer - 5100013577×4
225100011682
$4.76
Bushing - 5100011682×2
235100013630
$37.24
Yoke spring - 5100013630×1
255100035091
$2.44
safety nut - 5100035091×2
915100013202
$33.95
Splash protection - 5100013202×1
925100013201
$33.95
Splash protection - 5100013201×1
935100012572
$20.09
Hexagon screw - 5100012572×2
945100012965
$3.01
Locking washer - 5100012965×2
