RD24-100o.3

RD24-100O.3 compactometer Diagram

Exploded parts diagram of the compactometer of a Wacker Neuson RD24-100O.3, with numbered balloons
Hover a box for the part, its price and its row below. Click it to select.
  • 305100073268Not stocked
    flange×1
  • 315100073269Not stocked
    knurled head screw×2
  • 335100035597
    $1.57
    o-ring seal - 5100035597×1
  • 355100073267Not stocked
    distance bush×1
  • 365100012608
    $1.57
    Hexagon screw - 5100012608×2
  • 365100013466
    $1.57
    Hexagon screw - 5100013466×2
  • 385100012965
    $3.01
    Locking washer - 5100012965×2
  • 405100033266Not stocked
    temperature probe×1
  • 455100073175Not stocked
    holder×1
  • 465100023046
    $2.84
    hexagon screw - 5100023046×1
  • 475100012965
    $3.01
    Locking washer - 5100012965×2
  • 485100012545
    $1.57
    Hexagon nut - 5100012545×1
