RD45-140.3

RD45-140.3 suspension Diagram

Exploded parts diagram of the suspension of a Wacker Neuson RD45-140.3, with numbered balloons
Hover a box for the part, its price and its row below. Click it to select.
  • 15100011836
    $1,114.43
    Spacer block - 5100011836Unknown×2
  • 15100065358Not stocked
    distance piece×2
  • 25100012415
    $20.16
    Hexagon screw M16x140 10.9 - 5100012415×4
  • 45100012186
    $1,881.04
    Bow plate - 5100012186×2
  • 55100011835
    $71.23
    Spacer plate - 5100011835×8
  • 65100013233
    $16.76
    Hexagon screw - 5100013233×10
  • 75100013235
    $18.12
    Hexagon screw - 5100013235×2
  • 85100012969
    $3.15
    Locking washer - 5100012969×12
  • 205100012309
    $710.67
    Ballast - 5100012309×4
  • 215100012947
    $11.35
    Stud bolt - 5100012947×8
  • 225100012969
    $3.15
    Locking washer - 5100012969×8
  • 235100012405
    $3.37
    Hexagon nut - 5100012405×8
  • 255100012968
    $1.57
    Locking washer - 5100012968×12
  • 265100011612
    $3.23
    Hexagon screw - 5100011612×12
