RD45-140 O Tandem Roller

RD45-140O TÜV italy Diagram

Exploded parts diagram of the TÜV italy of a Wacker Neuson RD45-140O, with numbered balloons
Hover a box for the part, its price and its row below. Click it to select.
  • 15100012143
    $521.50
    Bracket - 5100012143×1
  • 25100012572
    $20.09
    Hexagon screw - 5100012572×4
  • 35100012965
    $3.01
    Locking washer - 5100012965×4
  • 125100013573
    $1.49
    Wire fastener - 5100013573×5
  • 205100012897Not stocked
    Metal plate×1
  • 215100034803
    $1.57
    hexagon screw - 5100034803×2
  • 225100012895Not stocked
    Spacer block×4
  • 235100013094
    $1.57
    Washer - 5100013094×4
  • 245100011476
    $1.49
    Safety nut - 5100011476×2
  • 305100011539
    $342.43
    Stay bar - 5100011539×1
  • 315100013510
    $1.57
    Hexagon screw - 5100013510×2
  • 325100012966
    $1.57
    Locking washer - 5100012966×4
  • 335100012546
    $1.57
    Hexagon nut - 5100012546×2
  • 405100011541
    $265.07
    Mirror - 5100011541×1
  • 1025100012632
    $996.97
    Wire harness (rear frame) - 5100012632×1
