Vibration Plate VP1340Aw CN
VP1340AWCN Wheel Kit cpl. old Diagram
- wheels cpl. - 5100037781×1
- Angle left - 5100018399×1
- Angle right cpl. - 5100037782×1
- WASHER-FLAT,M8,ZINC - 5000010622×8
- SCREW M8 X 30 SOC.HD. - 5000011541×4
- NUT-LOCK VM8 HEX - 5000033356×4
- WASHER B6.4 FLAT - 5000010373×3
- SCREW M6 X 16 SOC.HD. - 5000011553×3
- SCREW M6 X 35 SOC.HD. - 5000011548×3
- Angle left - 5100018400×1
- Hook cpl. - 5100027076×1
- Shockmount 30 x 15 - 5100016317×1
- SCREW M10 X 30 SOC.HD. - 5000011534×1
- WASHER-LOCK 10 - 5000033988×1
- WASHER B21 FLAT - 5000010616×1
- NUT-LOCK VM8 HEX - 5000033356×1
- Angle - 5100037765×1
- Bush - 5100037766×4
- gear rod - 5100037772×1
- gear rod - 5100037770×1
- Plate - 5100037767×1
- Gear - 5100037769×1
- Axle - 5100037768×1
- NUT M12 8,HEX - 5000010884×1
- KNOB - 5000097454×1
- WASHER B5.3 FLAT - 5000010372×1
- SCREW M5 X 12 SOC.HD. - 5000043307×1
- SCREW M8 X 20 HX.HD. - 5000012362×4
- Trolley - 5100018385×1
- Lock washer - 5000103834×4
- WASHER B21 FLAT - 5000010616×4
- WHEEL 140 X 37.5,RUBBER - 5000021466×2
- 375100028844Not stockedWheel Kit cpl.×1
