Articulated wheel loader WL28

WL28 wheel cover Diagram

Exploded parts diagram of the wheel cover of a Wacker Neuson WL28, with numbered balloons
Hover a box for the part, its price and its row below. Click it to select.
  • 11000473825Not stocked
    clamp strap×2
  • 21000210021
    $310.23
    FENDER - 1000210021×2
  • 31000085467
    $0.98
    cheese head screw - 1000085467×2
  • 41000015431Not stocked
    washer×6
  • 51000013022Not stocked
    hexagon nut×2
  • 61000048558Not stocked
    flat head screw×2
  • 71000030951Not stocked
    spring washer×2
  • 81000015406Not stocked
    hexagon nut×2
  • 91000200330
    $9.85
    ANTISLIDE COVERING - 1000200330×0.5
