WL32

WL32 bracket compressor Diagram

Exploded parts diagram of the bracket compressor of a Wacker Neuson WL32, with numbered balloons
Hover a box for the part, its price and its row below. Click it to select.
  • 11000378892
    $1,184.30
    Bracket - 1000378892×1
  • 21000211031
    $500.37
    belt pulley - 1000211031×1
  • 31000329792Not stocked
    v-belt×1
  • 41000378903Not stocked
    connection sleeve×1
  • 51000295118
    $45.54
    thread plate - 1000295118×1
  • 61000085476
    $1.13
    cheese head screw - 1000085476×3
  • 71000131405
    $2.79
    cheese head screw - 1000131405×2
  • 81000015364Not stocked
    hex screw×2
  • 91000308474Not stocked
    thread rod×1
  • 101000015432
    $0.05
    washer 10,5 A2C DIN125 - 1000015432×8
  • 111000179163
    $17.40
    Plate - 1000179163×2
  • 121000015407Not stocked
    hexagon nut×1
  • 131000047392Not stocked
    hex screw×3
  • 141000354415
    $103.54
    shim - 1000354415×1
  • 151000379801Not stocked
    refrigerant sticker×1
