WP1550e
WP1550E battery holder Diagram
- Combi cylinder head screw M 8x 20 - 5100042618×4
- Shim screw 10x16 - 5100005556×2
- NUT-LOCK VM8 HEX - 5000033356×2
- Foam - 5100002878×1
- Leg spring - 5100025600×2
- Locking plate - 5100054130×1
- Cable - 5100059794×1
- Screw M 6x 16 - 5100063195×4
- 905100060924Not stockedConverter cpl.×1
- SCREW M6 X 8 SOC.HD. - 5000014425×3
- WASHER B6.4 FLAT - 5000010624×3
- SCREW M6 X 20 - 5000108372×2
- Screw - 5000222073×4
- Clamp - 5100000179×2
- Bracket - 5100025637×1
- Head Screw 5x16 - 5100010127×2
- Plug cpl. - 5100001742×1
- Switch - 5100045196×1
