SPARE PARTS LIST 2700/5002 SP
Despiece de front part · 2700/5002
- 11000078333No la vendemosfront frame×1
- 21000013367No la vendemosslewing ring×1
- 31000078019No la vendemosswivel console×1
- 41000018577No la vendemospowerswivel×1
- 51000013369No la vendemosswivel centering×1
- 61000078201No la vendemosdust catch bracket×1
- 71000004819No la vendemosswing metal buffer×4
- 81000065197No la vendemosdust catch×2
- 91000065198No la vendemosfastener rail×2
- 101000078402No la vendemosbracket hose×1
- 111000013358No la vendemosbearing plate×2
- 121000015622No la vendemosdx bushing×4
- 131000013357No la vendemosmaintenance support×1
- 141000064951No la vendemosbucket support×2
- 151000013310No la vendemospin×6
- 161000013370No la vendemosbucket tilt pin×2
- 171000013371No la vendemospin piece×2
- 181000082664No la vendemoswasher×6
- cotterpin - 1000085659×8
- DIN933 M12x45 10.9 A2C - 1000085440×16
- 211000015453No la vendemosnorthlock disc×32
- HEXAGON NUT - 1000082563×16
- DIN985-M8-8-A2C - 1000015416×1
- HEX SCREW - 1000085429×8
- 251000015451No la vendemosnorthlock disc×16
- 261000015423No la vendemoshexagon nut×8
- HEXAGON NUT - 1000085587×8
- 281000018447No la vendemoshex screw×1
- 291000015475No la vendemosgrease nipple×1
- CHEESE HEAD SCREW - 1000082415×2
- lock washer - 1000082609×2
- 321000082663No la vendemosu-washer×6
- 331000020189No la vendemoscheese head screw×6
- 341000015443No la vendemoslock washer×2
- 351000015457No la vendemoscotter pin×1
- cotter pin - 1000085652×1
- 6-Point screw M8x30-8.8 A2C-DIN933 - 1000085390×2
- 381000015448No la vendemoswasher×2
- DIN985-M8-8-A2C - 1000015416×2
- Hex Screw M10x25-8.8 A2K-DIN933 - 1000015345×2
- 411000015438No la vendemoslock washer×10
- hex screw M10x20-8.8 A2C DIN933 - 1000085411×4
- 431000015407No la vendemoshexagon nut×4
- hex screw - 1000085378×8
- spring washer - 1000082621×8
