A1500-POWER UNIT,HONDA,35CC
Despiece de Transmission complete · A1500/035ISO
- Housing - 5000218775×1
- COVER-HOUSING - 5000218774×1
- Hub - 5000218942×1
- DRUM-CLUTCH - 5000218116×1
- Axle - 5000218786×1
- WASHER-FLAT,M8,ZINC - 5000010622×1
- NUT-LOCK M8 HEX - 5000010367×1
- BEARING-BALL,GROOVED - 5000218540×1
- RET.RING-EXT 17MMX1MM, - 5002001038×1
- RET.RING-INT 35MMX1.5MM, - 5002003694×1
- SCREW M10 X 35 SOC.HD. - 5000011533×2
- DETENT PIN CPL. - 5000218480×1
- V-BELT,RIBBED - 5000218963×1
- WASHER B10.5 FLAT - 5000010621×3
- Plug - 5000219489×1
- Hub - 5000218119×1
- ADAPTER-FLEXSHAFT - 5000053934×1
- SPACER-BUSHING - 5000218429×1
- SPACER-BUSHING - 5000218395×1
- SHAFT-DRIVING - 5000218118×1
- BEARING-BALL,GROOVED - 5000218541×1
- RET.RING-INT 35MMX1.5MM, - 5002003694×1
- BEARING-BALL,GROOVED - 5000218540×1
- PIN-DETENT - 5000071184×1
- STUD HOUSING - 5000218482×1
- Spring - 5000071189×1
- KNOB-T - 5000083074×1
