Generator GH 3500
Despiece de Camshaft cpl. · GH3500
- PIN-CAMSHAFT - 5000156471×1
- O-Ring - 5000156472×1
- PIN-SPRING - 5000156473×1
- LEVER-RELEASE - 5000156474×1
- CLIP - 5000156475×1
- SPRING-RETURN - 5000205123×1
- SPRING-VALVE - 5000156477×2
- RETAINER-SPRING,VALVE - 5000156478×2
- VALVE-INTAKE - 5000156479×1
- VALVE-EXHAUST - 5000156480×1
- HOLDER-VALVE - 5000156481×4
- CHAIN-DRIVE - 5000208300×1
- CRANK - 5000156483×1
- SPRING-TENSION - 5000156484×1
- PIN-TENSIONER - 5000156485×1
- GUIDE-CHAIN - 5000156486×1
- X-5200001097 PIN-ROCKER - 5000205304×1
- CLIP - 5000156106×1
- ROCKER ARM-INLET - 5000205128×1
- ROCKER ARM-EXHAUST - 5000205129×1
- SCREW-ADJUSTMENT - 5000205130×2
- nut - 5000205131×2
- 2905000053612No la vendemosScrew×1
- 3105000156492No la vendemosExhaust cpl.×1
- GUARD-MUFFLER - 5000156495×1
- GASKET-MUFFLER - 5000203771×1
- X-5000075270 NUT-FLANGE - 5000156497×2
- BOLT-TAPPING - 5000117241×2
- BOLT-FLANGE - 5000156645×1
- screw - 5000205305×1
- SCREEN COMPLETE - 5000156591×1
- SCREW-SELF TAPPING - 5000156494×2
- INSULATOR - 5000205146×1
- GASKET-CARBURETOR - 5000205148×1
- GASKET-CARBURETOR - 5000205147×1
- NUT M6,HEX,FLANGE - 5000053616×2
- BOLT-FLANGE - 5000156503×1
- 8505000208301No la vendemosBreather tube×1
