HSH 380B-Natural Gas/Propane, w/o Generator
Despiece de Control Panel Mount · HSH380B
- 255200016638No la vendemosControl box mounting panel×1
- 285200016661No la vendemosValve cover×1
- 395200016255No la vendemosBracket×1
- 2115200012331No la vendemosControl panel×1
- 2175000173883No la vendemosPressure gauge×1
- LATCH STRIKE,WIRE - 5000158982×2
- 3065000168367No la vendemosHose barb×1
- 3425200019761No la vendemosCoupling×1
- 4055000168481No la vendemosThermometer×1
- 4175200014433No la vendemosPower cable×1
- 4295200014426No la vendemosWiring harness×1
- 4305200014427No la vendemosWiring harness×1
- 4325200014429No la vendemosWiring harness×1
- 4385200019243No la vendemosCable cpl., burner×1
- SCREW M8X20 HX.HD.,SST - 5000158897×2
- SCREW M6 X 25 HX.HD. - 5000011469×4
- WASHER-B8.4 FLAT,2THK,20 OD - 5000160298×4
- SCREW M6 X 16 HX.HD. - 5000014663×7
- WASHER B3.2 FLAT - 5000010632×6
- SCREW M8 X 14,HX.HD,SERR.FLG - 5000157021×4
- 5385000192389No la vendemosFlat washer×8
- 5415000192393No la vendemosFlat washer×11
- 5485000173965No la vendemosLock washer×8
- 5535200014947No la vendemosScrew×2
- 5575000173985No la vendemosHexagonal head cap screw×4
- SCREW M3 X 16 PHIL HD - 5000110485×6
- NUT-LOCK M3 HEX - 5000086710×6
- 5975000168769No la vendemosGrommet×4
- 6365200012200No la vendemosLabel-control panel×1
