RD 16-100

Despiece de Front Drum · RD16-100

Despiece del Front Drum de una máquina Wacker Neuson RD16-100, con globos numerados
Pasa por encima de un recuadro para ver la pieza, su precio y su fila. Pincha para marcarla.
  • 15000172004
    $3,397.31
    DRUM-VIBRATORY,1000MM - 5000172004×1
  • 45000111119
    $19.47
    COVER-DRUM SUPPORT P-5000176420 - 5000111119×2
  • 55000161189
    $535.59
    BRACKET-DRUM SUPPORT P-5000176420 - 5000161189×1
  • 65000111060
    $210.50
    BRACKET-DRUM SUPPORT P-5000176420 - 5000111060×1
  • 85000111096
    $41.31
    HOUSING-BEARING P-5000176420 - 5000111096×1
  • 105000161068
    $95.70
    PLATE-DRIVE P-5000176420 - 5000161068×1
  • 115000111056
    $83.60
    PLATE-SHOCKMOUNT P-5000176420 - 5000111056×1
  • 145000163364
    $5,482.00
    MOTOR-DRIVE,RD16, BLACK - 5000163364Se desconoce×1
  • 145000176327No la vendemos
    Seal Kit×1
  • 225000111052
    $50.73
    SHOCKMOUNT - 5000111052×3
  • 235000162949
    $216.43
    SHOCKMOUNT,4 - 5000162949×3
  • 255000162952
    $136.63
    MOUNT-EXCITER MOTOR P-5000176420 - 5000162952×1
  • 285000172811
    $196.06
    SPACER-MACHINED P-5000176420 - 5000172811×2
  • 3705000163980
    $97.48
    HOSE-RD16,MTR FRT TO MTR AFT - 5000163980×1
  • 3735000173026
    $62.04
    HOSE-RD16,BRK REL T TO FRT MTR - 5000173026×1
  • 3795000173030
    $32.82
    HOSE-RD16,DRAIN MTR FRT TO T F - 5000173030×1
  • 3865000173034
    $44.95
    HOSE-STEEL,REAR MOTOR - 5000173034×1
  • 3875000173033
    $305.43
    HOSE-STEEL,FRNT MOTOR R - 5000173033×1
  • 3985000081583
    $4.00
    FITTING #8 - 5000081583×2
  • 3985000080732
    $0.32
    O-RING .644 X.087 DURO90 3-908 - 5000080732×1
  • 3985000080737
    $0.15
    O-RING .49 X .07 #8 ORFS 2-014 - 5000080737×1
  • 4015000112405
    $5.40
    FITTING-HYD. 4-6 ST. - 5000112405×1
  • 4015000080730
    $0.19
    O-RING .351 X.072 DURO90 3-904 - 5000080730×1
  • 4015000080736
    $0.19
    O-RING .36 X .07 #6 ORFS 2-012 - 5000080736×1
  • 4025000164189
    $13.68
    FITTING-ST-#6 ORFS-#5 ORB - 5000164189×1
  • 6365000164045
    $1.21
    NUT-M12,HX.HD,FLG ZN,8.8 - 5000164045×12
  • 6665000011534
    $0.94
    SCREW M10 X 30 SOC.HD. - 5000011534×6
  • 6735000172301
    $1.65
    SCREW M12-1.75X80,SOC.HD.,10.9 - 5000172301×8
  • 6745000011423
    $0.75
    SCREW M12 X 30 HX.HD. - 5000011423×7
  • 6825000011523
    $1.08
    SCREW M16 X 30 HX.HD. - 5000011523×5
  • 7035000087023
    $0.35
    SCREW M8 X 22,HX.HD,SER.FLG - 5000087023×8
  • 7335000031565
    $0.48
    WASHER-LOCK A12 - 5000031565×12
  • 7355000153532
    $3.16
    WASHER-LOCK M16 CON SPR,MZP - 5000153532×5
