WN Dumper 6001

6001 control valve (Option) Diagram

Exploded parts diagram of the control valve (Option) of a Wacker Neuson 6001, with numbered balloons
Hover a box for the part, its price and its row below. Click it to select.
  • 11000158958
    $816.15
    Controlvalve 1000158958×1
  • 21000166700
    $18.12
    Lever Adapter - 1000166700×1
  • 31000082587
    $0.70
    HEXAGON NUT - 1000082587×1
  • 41000068345
    $11.42
    GN539-23-M10 - 1000068345×1
  • 51000167131
    $26.35
    VALVE COVER - 1000167131×1
  • 61000022334Not stocked
    hex screw×3
  • 71000015448Not stocked
    washer×6
  • 81000015416
    $0.71
    DIN985-M8-8-A2C - 1000015416×3
  • 91000015494Not stocked
    screw joint×2
  • 101000015506Not stocked
    screw joint×2
  • 111000015490Not stocked
    screw joint×1
  • 121000015491Not stocked
    screw joint×1
  • 131000021496Not stocked
    screw joint×1
  • 141000015512Not stocked
    screw joint×1
  • 151000020801
    $12.87
    GZ15LA3C - 1000020801×1
  • 161000028582Not stocked
    minimess point×1
  • 171000085128
    $3.13
    GE12LR1/4EDOMDA3C - 1000085128×2
  • 181000173372
    $239.78
    lever fastening set - 1000173372×1
  • 191000095097
    $1.38
    O-RING - 1000095097×2
  • 201000095091
    $0.38
    O-RING - 1000095091×4
  • 211000173346
    $33.23
    back adjust stick set - 1000173346×2
  • 221000152286
    $84.01
    pressure limit reliefvalve - 1000152286×1
  • 231000228724
    $26.44
    BELLOW - 1000228724×1
