WN Dumper 6001

6001 Reversing Camera (OPTION) Diagram

Exploded parts diagram of the Reversing Camera (OPTION) of a Wacker Neuson 6001, with numbered balloons
Hover a box for the part, its price and its row below. Click it to select.
  • 11000344889Not stocked
    rear view camera×1
  • 21000344888
    $869.10
    monitor - 1000344888×1
  • 31000344921
    $77.09
    CABLE - 1000344921×1
  • 41000346975Not stocked
    sun visor×1
  • 51000344825
    $47.75
    plate - 1000344825×1
  • 61000353461
    $23.19
    BRACKET - 1000353461×1
  • 71000341985Not stocked
    bracket×1
  • 81000167330
    $10.32
    starhandle screw - 1000167330×1
  • 91000015343Not stocked
    hex screw×2
  • 101000085375
    $0.69
    hex screw - 1000085375×4
  • 111000094961
    $1.71
    washer 4,3 DIN125 - 1000094961×4
  • 121000015448Not stocked
    washer×2
  • 131000015437Not stocked
    lock washer×2
  • 141000013021Not stocked
    hexagon nut×2
  • 151000082612
    $0.65
    lock washer - 1000082612×4
  • 161000360292Not stocked
    inner hexagon screw×4
  • 171000027445Not stocked
    pin housing×1
  • 181000085028Not stocked
    pin contact×2
  • 191000027449Not stocked
    wedge×1
  • 201000257052
    $119.46
    protecting bar - 1000257052×1
  • 211000085378
    $0.70
    hex screw - 1000085378×2
  • 221000269459
    $101.46
    BRACKET - 1000269459×1
  • 231000094967
    $0.65
    Washer M5,3-DIN134 - 1000094967×2
  • 241000019136Not stocked
    hex screw×2
  • 251000015431Not stocked
    washer×2
