WN Dumper 6001

6001 CABIN HEADLIGHT (OPTION) Diagram

Exploded parts diagram of the CABIN HEADLIGHT (OPTION) of a Wacker Neuson 6001, with numbered balloons
Hover a box for the part, its price and its row below. Click it to select.
  • 11000270919
    $56.13
    working light - 1000270919×2
  • 21000015293Not stocked
    bulb×2
  • 31000081957
    $21.80
    TILT SWITCH - 1000081957×1
  • 41000029806
    $12.01
    symbol - 1000029806×1
  • 51000265159
    $193.80
    light cable - 1000265159×1
  • 61000135585
    $67.78
    bracket headlight - 1000135585×1
  • 71000135585
    $67.78
    bracket headlight - 1000135585×1
  • 81000094966
    $0.65
    washer M6,4-DIN134 - 1000094966×4
  • 91000020553Not stocked
    hex screw×4
  • 101000073525
    $1.49
    cover cap - 1000073525×4
  • 111000124830
    $6.29
    CABLE CLIP - 1000124830×5
  • 121000022016Not stocked
    spring washer×2
  • 131000015408
    $1.33
    nut M10-8 A2C-DIN985 - 1000015408×2
  • 141000267847Not stocked
    RETROFIT KIT - CABIN HEADLIGHT×1
