WN Dumper 6001

6001 clearance lamp (Option) Diagram

Exploded parts diagram of the clearance lamp (Option) of a Wacker Neuson 6001, with numbered balloons
Hover a box for the part, its price and its row below. Click it to select.
  • 11000078871
    $21.53
    surround light - 1000078871×2
  • lamp - 1000001520×2
  • hex screw - 1000085379×8
  • HEXAGON NUT - 1000085587×8
  • 51000237745
    $61.88
    cable - 1000237745×2
  • 61000085028Not stocked
    pin contact×4
  • 71000027445Not stocked
    pin housing×2
  • washer A 5,3 A2C DIN125 - 1000094962×16
  • 91000027449Not stocked
    wedge×2
  • 101000027442Not stocked
    wedge×2
  • 111000268012
    $376.56
    retrofit kit Clearance lamp - 1000268012×1
  • X8.11000000481Not stocked
    plug housing×2
  • X8.21000027438Not stocked
    bushing housing×2
