WN Dumper 6001

6001 Reversing Camera (OPTION) Diagram

Exploded parts diagram of the Reversing Camera (OPTION) of a Wacker Neuson 6001, with numbered balloons
Hover a box for the part, its price and its row below. Click it to select.
  • 11000173577
    $2,527.67
    KIT Camera - 1000173577×1
  • 21000468676
    $427.23
    Camera - 1000468676×1
  • 31000257302
    $1,364.21
    monitor - 1000257302×1
  • 41000257303
    $101.18
    cable - 1000257303×1
  • 51000095330Not stocked
    plug sleeve×1
  • 61000095370
    $0.66
    plug sleeve - 1000095370×1
  • 71000256828
    $85.43
    box - 1000256828×1
  • 81000256827
    $433.80
    COVER - 1000256827×1
  • 91000256826
    $39.92
    bracket - 1000256826×1
  • 101000085557
    $0.78
    flat head screw - 1000085557×2
  • 111000015373Not stocked
    countersunk screw×2
  • 121000015448Not stocked
    washer×3
  • 131000013021Not stocked
    hexagon nut×2
  • 141000094967
    $0.65
    Washer M5,3-DIN134 - 1000094967×2
  • 151000256825
    $39.52
    hinge pin - 1000256825×1
  • 161000015429Not stocked
    starhandle nut×1
  • 171000082326
    $1.38
    thread pin - 1000082326×1
  • 181000181084
    $8.91
    EDGE PROTECTION - 1000181084×0.8
  • 191000085378
    $0.70
    hex screw - 1000085378×2
  • 201000269459
    $101.46
    BRACKET - 1000269459×1
  • 211000258234
    $142.77
    Cover Plate - 1000258234×1
  • 221000271008Not stocked
    RETROFIT KIT Reversing Camera×1
