Vibration Plate BPU 2950A WSM

BPU2950A Air Filter Insert cpl. Diagram

Exploded parts diagram of the Air Filter Insert cpl. of a Wacker Neuson BPU2950A, with numbered balloons — Hover a box for the part, its price and its row below. Click it to select.

15000074744
$3.77
GASKET-AIR CLEANER MOUNT - 5000074744×1
25000074737
$35.33
ELEMENT-AIR FILTER - 5000074737×1
35000076373
$12.65
ELEMENT-AIR FILTER PRECLEANER - 5000076373×1
45000081670
$69.45
COVER-AIR CLEANER - 5000081670×1
55000072343
$6.93
GROMMET .240 ID,METALCLAD - 5000072343×1
65000068965
$27.60
SUPPORT-FILTER HOLDER - 5000068965×1
75000076371
$42.24
MOUNT-AIR CLEANER ELBOW - 5000076371×1
85000071621
$7.20
NUT-WING M6 - 5000071621×2
95000071036
$2.43
SCREW M6 X 20 W/FW,HEX.FLANGED - 5000071036×1
105000071056
$1.01
NUT M6,HEX,FLANGE - 5000071056×2
115000081636
$71.74
MUFFLER - 5000081636×1
125000081637
$89.95
GUARD-MUFFLER - 5000081637×1
135000115592
$45.17
GUARD-EXHAUST PIPE - 5000115592×1
145000081639
$92.17
PIPE-EXHAUST - 5000081639×1
155000110252
$6.49
GASKET-MUFFLER,STL - 5000110252×1
165000074742
$17.57
GASKET-MUFFLER - 5000074742×1
175000053990
$2.33
SCREW M6 X 12,HX.FLANGE HD. - 5000053990×1
185000071070
$2.73
SCREW M5 X 8,TAPPING - 5000071070×4
195000074745
$13.63
CAP-EXHAUST DEFLECTOR - 5000074745×1
205000150916
$1.30
SCREW-TAPPING 4 X 6 - 5000150916×3
215000074738
$1.45
NUT M8,HEX.FLANGE - 5000074738×5
225000081764
$6.03
hose cover - 5000081764×1
235000071083
$14.92
FILTER-FUEL,INTANK - 5000071083×1
245000076369
$368.49
TANK-FUEL - 5000076369×1
255000081662
$23.25
CAP-FUEL TANK - 5000081662×1
265000106947Not stocked
Seal×1
275000071082
$4.75
O-RING 14 X 1.3 - 5000071082×1
285000074750
$8.28
NLA HOSE 4.5X222MM,FUEL LINE X5100000455 - 5000074750×1
295000054136
$2.72
CLAMP B8,HOSE CLIP - 5000054136×2
305000074751
$2.70
SCREW M8 X 25,HEX.FLANGED - 5000074751×2
