Vibration Plate BPU 2950A WSM

BPU2950A Cylinder Head cpl. Diagram

Exploded parts diagram of the Cylinder Head cpl. of a Wacker Neuson BPU2950A, with numbered balloons
Hover a box for the part, its price and its row below. Click it to select.
  • 15000081623
    $543.70
    CYLINDER-HEAD,COMPLETE - 5000081623×1
  • 25000084643
    $26.72
    GASKET-CYLINDER HEAD - 5000084643×1
  • 35000089273
    $77.37
    COVER-CYLINDER HEAD - 5000089273×1
  • 45000074646Not stocked
    Hose piece×1
  • 55000074645
    $15.43
    GASKET-CYLINDER HEAD COVER - 5000074645×1
  • 65000074655
    $8.04
    BOLT-CYL.HEAD COVER RETAINER - 5000074655×1
  • 75000074651
    $10.66
    STUD M8 X 127 - 5000074651×2
  • 85000074654Not stocked
    Stud×2
  • 95000074657
    $7.71
    WASHER - 5000074657×1
  • 105000074652
    $3.70
    PIN 12 X 20,DOWEL - 5000074652×2
  • 115000070947Not stocked
    Spark plug×1
  • 125000074647
    $4.94
    SCREW M10 X 80,HEX.FLANGED - 5000074647×4
  • 135000107026Not stocked
    Cylinder housing cpl.×1
  • 145000075790
    $75.23
    SWITCH-OIL ALERT,COMPLETE - 5000075790×1
  • 155000074641
    $14.98
    Shaft - 5000074641×1
  • 165000089268
    $8.47
    WIRING HARNESS - 5000089268×1
  • 175000053990
    $2.33
    SCREW M6 X 12,HX.FLANGE HD. - 5000053990×1
  • 185000053993
    $10.66
    PLUG M12,HEX.FLANGE - 5000053993×2
  • 195000074657
    $7.71
    WASHER - 5000074657×1
  • 205000071699
    $15.14
    shaft seal - 5000071699×2
