CRT48-31V-ES RIDE-ON TROWEL
CRT48-31V-ES Drive cpl. Diagram
- BRACKET-SECONDARY MOUNT - 5000155097×2
- 965000162740Not stockedLever cpl. (right cross)×1
- 985000162743Not stockedLever cpl. (left cross)×1
- BRACKET-GEARBOX PIVOT,LEFT - 5000119189×1
- 1805000150085Not stockedBracket×1
- SPACER-JACKSHAFT LONG - 5000154728×1
- 2115000116788Not stockedClutch×1
- 2155000164292Not stockedClutch×1
- BELT-DRIVE - 5000164291×1
- UNIVERSAL JOINT-SHORT,ASSEMBLY - 5000117999×2
- BEARING-DRIVESHAFT - 5000117341×2
- WASHER 1 ODX.265 IDX.1795 - 5000117353×2
- SHIM-UNIVERSAL JOINT - 5000117644×2
- SHAFT-LONG - 5000117984×1
- SPACER-JACKSHAFT SHORT - 5000154727×1
- FITTING-INNER JOINT - 5000117627×2
- CAP-GREASE FITTING,RED - 5000155804×14
- SCREW M6 X 20 SOC.HD. - 5000011551×16
- SCREW M6 X 20 HX.HD. - 5000011470×2
- SCREW M12 X 65 HX.HD. - 5000011304×8
- Din 933 M14x45 10.9 - 5000118606×4
- SCREW 7/16-20 X 4-1/2 ,HHCS - 5000151742×1
- SCREW M12 X 40 HX.HD. - 5000011421×8
- NUT-LOCK M12X1.75 HEX - 5000010366×8
- SCREW M12 X 45 HX.HD. - 5000011420×4
- WASHER .531X 1.625X.120,FLAT - 5000114766×1
- WASHER B13 FLAT - 5000010620×16
- KEY-SQUARE 3/16 X 1.000 - 5000073890×2
- KEY-SQUARE 1/4 X 1 - 5000027751×2
- KEY-SQUARE 1/4 X 2-3/16 - 5003012513×1
- BEARING-FLANGE 1 ID - 5000116765×6
- BLOCK-BUSHING,1-1/8 BORE P-5000176420 - 5000162737×6
