CRT48-31V-ES RIDE-ON TROWEL

CRT48-31V-ES Transport Kit Diagram

Exploded parts diagram of the Transport Kit of a Wacker Neuson CRT48-31V-ES, with numbered balloons
Hover a box for the part, its price and its row below. Click it to select.
  • 15000160259
    $3,031.25
    KIT-TRANSPORT DOLLY - 5000160259×1
  • 25000158914
    $123.76
    TUBE-SLIDING WELDMENT P-5000112007 - 5000158914×1
  • 35000152457
    $8.53
    HANDLE-GRIP,CRT - 5000152457×2
  • 45000160282
    $3.54
    PIN-SAFETY,SNAP - 5000160282×1
  • 55000158915
    $501.02
    HANDLE-WHEEL WELDMENT P-5000112007 - 5000158915×1
  • 65002005276
    $0.99
    PIN 3-9/16 LONG,COTTER - 5002005276×2
  • 75000116751
    $0.28
    PIN-COTTER 1/8 X 1-1/2 - 5000116751×4
  • 85000025641
    $0.58
    WASHER 1 NOM,STEEL,FLAT - 5000025641×2
  • 95002005109
    $94.35
    WHEEL 480/400-8,16 DIA,2PLY - 5002005109×2
  • 105000010618
    $0.28
    WASHER B17 FLAT - 5000010618×2
  • 115000158918
    $210.31
    AXLE-WHEEL 16 P-5000112007 - 5000158918×2
  • 125000158916
    $20.27
    WHEEL 8 in - 5000158916×2
