CRT48-57K Trowel

CRT48-57K-MS Fuel Hose Routing Diagram

Exploded parts diagram of the Fuel Hose Routing of a Wacker Neuson CRT48-57K-MS, with numbered balloons — Hover a box for the part, its price and its row below. Click it to select.

425200009133
$524.62
Tank-Fuel,CRT48 - 5200009133×1
435100014310
$140.38
Cap-Ratchet 350 Fuel, Control Vent - 5100014310×1
455000110586
$3.70
BUSHING-FUEL VALVE - 5000110586×1
1825000028707
$0.67
CLAMP-THREADED,.21-.63 - 5000028707×4
1855200015956Not stocked
Fuel valve×1
2715000186628
$1.32
GROMMET-ROLLOVER VENT,BUNA-N - 5000186628×1
2735000193330
$9.36
FITTING-FUEL RETURN - 5000193330×1
2785100014021
$35.05
BRACKET-FUEL PUMP - 5100014021×1
4535000029117
$0.03
NUT-LOCK M6,HEX,SERR,FLANGE - 5000029117×2
6805100013979
$8.61
FITTING-SAE#4 MORB MALE to 1/4 BARB - 5100013979×1
6815100014031
$6.85
ADAPTER-SAE#6 MORB MALE to SAE#5 MALE - 5100014031×1
6825100014031
$6.85
ADAPTER-SAE#6 MORB MALE to SAE#5 MALE - 5100014031×1
6835100014032
$30.03
FITTING-SAE#5 FEMALE to 5/16 BARB - 5100014032×1
6845100014033
$30.89
ADAPTER-M10 MALE to SAE#4 MALE - 5100014033×1
6855100014034
$7.57
FITTING-#4 FEMALE to 1/4 BARB - 5100014034×1
6865100014321
$12.92
FITTING-SAE#6 MALE to 90DEG,5/16 BARB - 5100014321×1
6875100015060
$8.07
FITTING-90DEG QUICK CONNECT,5/16 - 5100015060×1
8215100018509
$442.76
ELECTRIC FUEL PUMP - KUBOTA - 5100018509×1
8225100018931
$3,311.33
Engine Control Unit-WG1605 Kubota - 5100018931×1
10305100018609
$6.27
HOSE-FUEL 5/16 X 12 IN - 5100018609×1
10305100018624
$5.22
LOOM, 10 IN - 5100018624×1
10315100018620
$13.85
HOSE-FUEL 5/16 X 16 IN - 5100018620×1
10315100018625
$7.30
LOOM, 14 IN - 5100018625×1
10325100018621
$10.97
HOSE-FUEL 5/16 X 21 IN - 5100018621×1
10325100018626
$5.29
LOOM, 19 IN - 5100018626×1
10335100018622
$24.33
HOSE-FUEL 5/16 X 48 IN - 5100018622×1
10335100018627
$24.01
LOOM, 46 in - 5100018627×1
10345100018623
$31.32
HOSE-FUEL 1/4 X 60 IN - 5100018623×1
10345100018628
$5.29
LOOM, 58 IN - 5100018628×1
11005100031373
$1,413.46
Fuel Manifold,Kubota - 5100031373×1
