DPU2950Y-VIBROPLATE

DPU2950Y Vibratory Plate cpl. Diagram

Exploded parts diagram of the Vibratory Plate cpl. of a Wacker Neuson DPU2950Y, with numbered balloons
Hover a box for the part, its price and its row below. Click it to select.
  • 15000105418
    $273.53
    PULLEY-V BELT - 5000105418×1
  • 25000047081
    $6.06
    RING BN32 X 12 - 5000047081×1
  • 35000033667
    $2.39
    SCREW M10 X 130 SOC.HD. - 5000033667×3
  • 45000047377
    $713.86
    BELTGUARD - 5000047377×1
  • 55000106884Not stocked
    Centrifugal clutch cpl.×1
  • 65000105419
    $16.49
    Bush - 5000105419×1
  • 75000105434
    $5.17
    Seal - 5000105434×1
  • 95000105415Not stocked
    Protective frame×1
  • 105000099867Not stocked
    Diesel engine×1
  • 115000098595
    $1.72
    BELLOWS-LEVER,DECOMPRESSION - 5000098595×1
  • 125000099927Not stocked
    Fixing bar×2
  • 135000010621
    $0.13
    WASHER B10.5 FLAT - 5000010621×4
  • 145000019141Not stocked
    Hexagon nut×4
  • 155000047280Not stocked
    V-belt pulley half×2
  • 165000047282Not stocked
    Distance washer×4
  • 175000058924
    $11.06
    BELT-V SPA882LW - 5000058924×1
  • 185000105411
    $24.74
    Bush - 5000105411×1
  • 195000028582
    $2.61
    SCREW 5/16-24 X 1-1/4,SOC.HD. - 5000028582×1
  • 205000010882
    $0.05
    NUT M8 8,HEX - 5000010882×9
  • 215000033198
    $0.32
    WASHER-LOCK B8 - 5000033198×8
  • 225000038428
    $1.60
    SCREW M10 X 80 SOC.HD. - 5000038428×1
  • 235000014316
    $0.98
    SCREW M12 X 16 HX.HD. - 5000014316×2
  • 245000106526Not stocked
    Plate×1
  • 255000017312Not stocked
    Hexagon nut×1
  • 265000017908
    $0.18
    SCREW M5 X 20 SOC.HD. - 5000017908×1
  • 275000011554
    $0.13
    SCREW M6 X 12 SOC.HD. - 5000011554×1
  • 285000106527Not stocked
    Plate×1
  • 295000106528
    $1.86
    Cable passage - 5000106528×1
  • 305000010740
    $0.23
    WASHER 13 - 5000010740×2
