DPU 3060H-TS-VIBROPLATE
DPU3060H-TS Exciter cpl. Diagram
- SCREW M6 X 18 SOC.HD. - 5000011552×8
- WASHER 6.4 - 5000010744×6
- cover - 5000126166×2
- BEARING-CYLINDER ROLLER - 5000105139×3
- KEY A10 X 8 X 18 - 5000014844×1
- SCREW M10 X 35,GR 10.9 - 5000049125×2
- WASHER-LOCK 10 - 5000033988×2
- EXCITER WEIGHT,BPU3050 - 5000125352×2
- shaft - 5000125341×1
- GEAR - 5000047057×1
- exciter housing - 5000125375×1
- SCREW M10 X 120 10.9 - 5000094073×8
- SEAL-ROTARY SHAFT - 5000126167×1
- COVER-BELT - 5000126159×1
- SCREW M6 X 30 SOC.HD. - 5000011549×6
- V-Belt Pulley - 5000125371×1
- WASHER-LOCK A12 - 5000031565×1
- SCREW-VENT - 5000126179×1
- cover - 5000125360×1
- WASHER B6.4 FLAT - 5000010373×6
- SCREW M6 X 20 HX.HD. - 5000011470×6
