DPU7060Fet
DPU7060FET Vibration Plate Diagram
- SCREW M8 X 20-ST, D7500 DE - 5000105944×6
- MOUNT-STRIP - 5000099047×2
- Plate - 5000099535×2
- SCREW M16 X 35 HX.HD. - 5000011522×4
- WASHER-LOCK HS16,HIGH TENSION - 5000021988×4
- FRAME-PROTECTIVE - 5000210168×1
- COVER-PROTECTIVE - 5000201543×1
- SCREW M8 X 16 SOC.HD. - 5000011544×6
- WASHER-FLAT,M8,ZINC - 5000010622×10
- GASKET-BATTERY BOX - 5000099928×1
- COVER - 5000201873×1
- PLUG M22 X 1.5 - 5000011052×1
- SEAL-RING 22 X 29 - 5000012084×1
- ADAPTER - 5000048930×1
- SCREW M6 X 25 SOC.HD. - 5000011550×2
- PLATE-STRIP - 5000039206×1
- COVER - 5000043478×1
- SCREW M8X18 SOC.HD. - 5000103962×6
- MOUNTING STRIP - 5000097110×2
- BELTGUARD - 5000048842×1
- SCREW M8 X 20 SOC.HD. - 5000011543×4
- WASHER B8.4 FLAT - 5000010374×4
- plate - 5000201870×1
- BELT-V BX39 - 5000058889×1
- GUARD - 5000045173×1
- 295000011530Not stockedCheese head screw×4
- WASHER-LOCK A12 - 5000031565×4
- SCREW - 5000216658×4
