DW40-2

DW40-2 DRIVE UNIT Diagram

Exploded parts diagram of the DRIVE UNIT of a Wacker Neuson DW40-2, with numbered balloons
Hover a box for the part, its price and its row below. Click it to select.
  • 11000485033
    $2,557.14
    MOTOR_VARIABLE - 1000485033×1
  • 21000085419
    $1.05
    hex screw - 1000085419×4
  • 31000015450Not stocked
    northlock disc×4
  • 41000147704
    $6.53
    GE18LM22X1,5OROMDA3C - 1000147704×1
  • 51000260785
    $33.13
    GE18LM27X2ORA3C - 1000260785×1
  • 61000515079
    $3,152.81
    DISTANCE PLATE - 1000515079×1
  • 71000445982Not stocked
    control part×1
  • 81000445947Not stocked
    washing valve×1
  • 91000090554
    $21.90
    O-RING - 1000090554×1
  • 101000315539Not stocked
    cheese head screw×4
  • 111000409127
    $247.18
    Solenoid - 1000409127×1
  • 121000502148Not stocked
    piston×1
  • 131000515080
    $131.09
    valve uiston - 1000515080×1
  • 141000266913
    $12.42
    O-ring - 1000266913×1
  • 151000266914
    $12.42
    O-ring - 1000266914×2
  • 161000090505
    $33.99
    O-RING - 1000090505×1
  • 171000501192
    $249.84
    Rotational speed sensor - 1000501192×1
  • 181000515081
    $27.92
    screw - 1000515081×1
