G70 Generator, Standard T4F

G70 Sheet Metal Assembly Diagram

Exploded parts diagram of the Sheet Metal Assembly of a Wacker Neuson G70, with numbered balloons
Hover a box for the part, its price and its row below. Click it to select.
  • 165100021158Not stocked
    Panel×1
  • 185100021159Not stocked
    Rear panel×1
  • 205100022038Not stocked
    Panel×1
  • 1015100021156Not stocked
    Panel×2
  • 1065100021913Not stocked
    Panel×1
  • 4155000179122Not stocked
    Plug×4
  • 6115000158118Not stocked
    Gasket×1
  • 6125000158849Not stocked
    Gasket×2
  • 6145100015120Not stocked
    Gasket×1
  • 6415000181530Not stocked
    Insulator-roof, front×1
  • 8385000028404Not stocked
    Hexagonal flange head screw×18
  • 8695000158897Not stocked
    Screw×34
  • 9635000158899Not stocked
    Flat washer×18
  • 9665000160626Not stocked
    Lock washer×20
