G85-GENERATOR,SKID BASE

G85 Engine/Generator cpl. Diagram

Exploded parts diagram of the Engine/Generator cpl. of a Wacker Neuson G85, with numbered balloons
Hover a box for the part, its price and its row below. Click it to select.
  • 5000115814
    $655.17
    DIODE-RECTIFIER ASSY - 5000115814×1
  • 5000115815
    $1,470.11
    EXCITER-ROTOR, CORE & COILS - 5000115815×1
  • 5000115816
    $2,864.75
    EXCITER-STATOR, CORE & COILS - 5000115816×1
  • 15000029116
    $0.18
    SCREW M6 X 1 X 20,FLANGE LOCK - 5000029116×4
  • 25000115176Not stocked
    Generator box cpl.×1
  • 35000115141Not stocked
    Generator×1
  • 45000115612Not stocked
    Hexagon nut×2
  • 55000115610Not stocked
    Lock washer×2
  • 65000010376
    $0.29
    WASHER A13 FLAT - 5000010376×4
  • 75000115135Not stocked
    Spacer×2
  • 85000115145Not stocked
    Shockmount×2
  • 95000115147Not stocked
    Washer×2
  • 105000115637Not stocked
    Hexagonal head cap screw×2
  • 115000115736Not stocked
    Screw×12
  • 125000025920Not stocked
    Hexagonal head cap screw×8
  • 145000115192Not stocked
    Engine cpl.×1
