LTV6K - Combo Hitch, Cold Weather
LTV6K Rear Enclosure cpl. Diagram
- LIGHT-TAIL, STRIP - 5100026478×2
- LIGHT-SIDE MARKER,RED - 5100026479×2
- LIGHT-LICENSE PLATE (AUX) - 5100026856×2
- SEAL RADIATOR BOTTOM - 5100030089×1
- COVER CONTROL - 5100026475×1
- HOOD FRAME LTV P-5000112007 - 5100026477×1
- LATCH DOOR CAM RECESSED - 5100028661×1
- HINGE ENCLOSURE - 5100026803×2
- HINGE CONTROL COVER - 5100031293×2
- HASP CONTROL COVER - 5100026476×1
- BRACKET HOOD FRAME - 5100031220×1
- TERMINAL DISC MALE INS 250 22-18 AWG - 5100031294×18
- MOUNT- Cable Tie, #10 Screw Hole - 5100029366×6
- SCREW M4 X 20 PHIL HD - 5000110951×8
- SCREW M5 X 16 HX.HD. - 5000011476×8
- SCREW M5X25 HX.HD. - 5000011474×2
- Screw M5 x 25,Socket Flat Hd BN21,12.9 - 5100029410×6
- SCREW M6 X 16,HX.HD,SER.FLG - 5000028949×2
- SCREW M6 X 25,SBHD,FLGE 10.9,BC - 5100030460×4
- SCREW M4 X 30 PHIL HD - 5000115527×4
- NUT-LOCK M4 HEX. - 5000010370×12
- NUT-LOCK M5 HEX. - 5000010369×10
- NUT-LOCK M6,HEX,SERR,FLANGE - 5000029117×6
- WASHER A4.3 FLAT - 5000010628×8
- WASHER B5.3 FLAT - 5000010625×10
