RD15-ROLLER,DOUBLE DRUM
RD15 Cylinder Head Diagram
- HEAD-CYLINDER - 5000107311×2
- STUD M8 X 25 - 5000010927×4
- STUD M8 X 40 - 5000013518×4
- GUIDE-VALVE - 5000128863×4
- STUD M8 X 35 - 5000010929×2
- STUD M8X85 - 5000107460×2
- STUD M8 X 30 - 5000010928×2
- VALVE-EXHAUST - 5000107313×2
- VALVE-INTAKE - 5000128864×2
- GASKET 0.50 - 5000107315×1
- GASKET 0.75 - 5000107320×1
- GASKET 0.70 - 5000107319×1
- GASKET 0.65 - 5000107318×1
- GASKET 0.60 - 5000107317×1
- GASKET 0.55 - 5000107316×1
- GASKET 0.80 - 5000107321×1
- GASKET 0.85 - 5000107322×1
- GASKET 0.90 - 5000107323×1
- GASKET 0.95 - 5000107324×1
- GASKET 1.00 - 5000107325×1
- GASKET 1.10 - 5000107326×1
- GASKET 1.20 - 5000107327×1
- Washer - 5000107328×4
- SPRING-VALVE - 5000107329×4
- SPRING-PLATE - 5000107330×4
- SET-TAPER,CONE VALVE - 5000094899×4
- RET.RING-EXT 15MMX1MM, - 5002001037×4
- WASHER-SUPPORT - 5000107331×4
- WASHER-SUPPORT - 5000107332×4
- ROCKER ARM-EXHAUST - 5000107333×2
- ROCKER ARM-INLET - 5000107334×2
- SCREW-ADJUSTING - 5000094891×4
- NUT-LOCK 5/16X24 - 5004101500×4
- ROCKER ARM-SUPPORT - 5000107335×2
- NUT-LOCK VM8 HEX - 5000033356×4
- GASKET - 5000107336×2
- Cover - 5000107337×2
- WASHER A8X14-CU - 5000107556×4
- SCREW M8 X 40 SOC.HD. - 5000011539×4
- 405000011080Not stockedEye bolt×1
- Nut - 5000107339×5
- Washer - 5000107340×8
- NUT-COLLAR - 5004101350×3
- RING-SEALING - 5000107342×4
- SCREW-M8 X 1 X 12 - 5000107444×1
- SCREW-HOLLOW 4-5-3 - 5000034365×2
- TUBE-OIL - 5000107341×1
- RING-SEALING - 5000107342×4
- Washer - 5000107343×1
