RD28-120c
RD28-120C main frame and assemblies Diagram
- Front frame part - 5100012170×1
- Locking washer - 5100012968×2
- Hexagon screw - 5100012626×2
- Metal plate - 5100012046×1
- Hexagon screw - 5100012626×4
- Locking washer - 5100012968×4
- Rear frame part - 5100012207×1
- Rear frame part - 5100012329×1
- Bow - 5100012786×1
- Hexagon screw - 5100011473×6
- Locking washer - 5100012969×6
- Rubber buffer - 5100011814×8
- Cheese-head screw - 5100011485×4
- Cheese-head screw - 5100011585×4
- Spacer block - 5100012350×8
- Seat pedestal - 5100012674×1
- Silentbloc - 5100012357×2
- Cheese-head screw - 5100012723×2
- Locking washer - 5100012965×2
- Locking washer - 5100012965×2
- Hexagon nut - 5100012545×1
- 405100033190Not stockedhexagon screw×2
- 415100033191Not stockedmetal plate×1
- Bushing - 5100012202×2
- Rubber metal buffer - 5100011734×2
- hexagon screw - 5100035014×2
- Washer - 5100013128×2
- cover - 5100016196×2
- Handle - 5100012853×2
- Filler cap - 5100012529×4
- Bushing - 5100016503×8
- Silentbloc - 5100011498×8
- Locking washer - 5100012966×8
- Stud bolt - 5100012946×4
- Stud bolt - 5100012977×4
- Hexagon nut - 5100012546×8
- Bottom plate - 5100016288×1
- Hexagon screw - 5100012617×6
- Washer - 5100013128×6
- Rubber metal buffer - 5100012712×2
- hexagon screw - 5100035014×2
- Washer - 5100013128×2
- Steering console - 5100012640Unknown×1
- 695100016289Not stockedSteering console×1
- Hexagon screw - 5100012517×4
- Washer - 5100013094×4
- Rubber profile - 5100013644×0.25
- 745100052877Not stockedprotective cap×2
- Spacer plate - 5100012652×1
- Hexagon screw - 5100012613×2
- Retaining plate - 5100012653×1
- Hexagon screw - 5100012515×2
- Locking washer - 5100012966×2
