RD40-130 O

RD40-130O edge pressing and cutting device add-on pieces Diagram

Exploded parts diagram of the edge pressing and cutting device add-on pieces of a Wacker Neuson RD40-130O, with numbered balloons
Hover a box for the part, its price and its row below. Click it to select.
  • 15100012466Not stocked
    Mounting device×2
  • 25100012726
    $2.88
    Cheese-head screw - 5100012726×4
  • 35100012968
    $1.57
    Locking washer - 5100012968×4
  • 55100013628Not stocked
    Pipe×2
  • 65100013128
    $1.09
    Washer - 5100013128×2
  • 75100013455
    $2.22
    Cheese-head screw - 5100013455×2
  • 105100033238Not stocked
    holder×1
  • 115100011767Not stocked
    Flange×2
  • 125100013450
    $1.57
    Cheese-head screw - 5100013450×4
  • 135100012967
    $1.57
    Locking washer - 5100012967×16
  • 145100012617
    $2.84
    Hexagon screw - 5100012617×16
  • 205100012520
    $1.57
    Hexagon screw - 5100012520×2
  • 305100012967
    $1.57
    Locking washer - 5100012967×2
  • 405100011789Not stocked
    Pipe×1
  • 505100011788Not stocked
    Bracket×1
  • 605100011790Not stocked
    Bolt×1
  • 705100013638Not stocked
    Indicator×1
  • 805100013509
    $1.57
    Washer - 5100013509×1
  • 905100011783Not stocked
    Hand lever×3
