RTL82-SC3
RTL82-SC3 Pulley cpl. Diagram
- PULLEY-CRANKSHAFT - 5000155723×1
- BOLT M16 X 1.5 - 5000126935×1
- BOLT M8 X 1.25 X 90 - 5000159490×1
- washer - 5000159346×1
- PULLEY ASSEMBLY - 5000159345Unknown×1
- 65200023964Not stockedPulley×1
- washer - 5000159347×1
- Bearing - 5000082135×2
- retaining ring - 5000159241×2
- PULLEY-HALF - 5000207987×1
- SPACER - 5000159277×1
- PIN-PILOT - 5000159489×1
- SPACER .5MM - 5000207988×2
- belt - 5000159262×1
- SCREW M8 X 35 - 5000083026×3
- BRACKET-FAN - 5000159448×1
- SPACER .1MM - 5000207989×4
- SCREW M6 X 1 X 40 - 5000159475×4
