RTL82-SC3
RTL82-SC3 Crankcase Diagram
- CRANKCASE-ENGINE - 5000210344×1
- sleeve - 5000159257×2
- Screw - 5000206229×1
- WASHER-COPPER - 5000082184×1
- Pin - 5000215522×1
- BEARING-SUPPORT (STD) - 5000155702×3
- BEARING-SUPPORT (-0.25) - 5000155703×3
- BEARING-SUPPORT (-0.50) - 5000155704×3
- WASHER-THRUST - 5000159486×2
- WASHER .10 - 5000159487×2
- WASHER .20 - 5000159488×2
- PLUG - 5000082335×4
- GASKET - 5000159288×4
- PIN-DOWEL - 5000159360×2
- screw - 5000159480×8
- plug - 5000159456×1
- WASHER-COPPER - 5000159299×1
- Plug - 5000215530×1
- Copper washer D14/10.2 1 - 5000082183×1
- GASKET SET,CRANKCASE - 5000159397×1
