VP2050AW Single Direction Vibratory Plate
VP2050AWUS Vibration Plate Diagram
- WASHER-FLAT,M8,ZINC - 5000010622×5
- Gas Engine GX160-UT2-QW-X2-SD - 5100018834×1
- SCREW M8 X 35 SOC.HD. - 5000011540×4
- ASM_Hose pipe cpl. - 5100002804×1
- Gasket - 5100018382×1
- Plate - 5100024871×1
- Plate - 5100018380×1
- SCREW 5/16-24 X 3/4,HX.HD. - 5000026169×5
- SCREW M8 X 20 HX.HD. - 5000012362×1
- Centrifugal clutch - 5100016313×1
- NUT-LOCK VM8 HEX - 5000033356×4
- Washer - 5100016321×1
- V-belt A-31 - 5100028101×1
- Belt guard - 5100018381×1
- SCREW - 5000216658×2
- Hose pipe - 5100002805×1
- Locking device - 5000206695×1
- PLATE - 5000206696×1
