Wheel Loader

WL16 steering unit Diagram

Exploded parts diagram of the steering unit of a Wacker Neuson WL16, with numbered balloons
Hover a box for the part, its price and its row below. Click it to select.
  • 11000230039
    $388.40
    Steeringcylinder 1000230039×1
  • 21000052119Not stocked
    hydraulic pump×1
  • 31000207490
    $1,032.74
    Hydrostaticsteering 1000207490×1
  • 41000192690
    $757.79
    Priorityvalve 1000192690×1
  • 51000198858
    $125.18
    Steeringwheel 1000198858×1
  • cover cap - 1000198962×1
  • 71000214282
    $125.60
    Rotary knob - 1000214282×1
  • 81000404335Not stocked
    screw joint×1
  • 91000224707
    $24.64
    Bolt - 1000224707×1
  • 101000224825
    $17.78
    Bearing - 1000224825×2
  • 111000223218
    $1.34
    Ring - 1000223218×4
  • 121000019253Not stocked
    lock ring×2
  • 131000222586
    $1.91
    Washer - 1000222586×2
  • 141000085411
    $1.37
    hex screw M10x20-8.8 A2C DIN933 - 1000085411×1
  • 151000022016Not stocked
    spring washer×1
  • 161000015432
    $0.05
    washer 10,5 A2C DIN125 - 1000015432×9
  • 171000015354
    $0.82
    allen screw M10x20-8.8 A2C-DIN912 - 1000015354×4
  • 181000022016Not stocked
    spring washer×4
  • 191000015364Not stocked
    hex screw×4
  • 201000015408
    $1.33
    nut M10-8 A2C-DIN985 - 1000015408×4
  • 211000222726
    $1.34
    NIPPLE-GREASE - 1000222726×1
  • 221000223029
    $1.06
    NIPPLE-GREASE - 1000223029×1
  • 231000224646
    $1.49
    Ring - 1000224646×1
  • 241000048165Not stocked
    cheese head screw×2
  • 251000048166Not stocked
    cheese head screw×2
  • 261000015444Not stocked
    spring washer×4
  • 271000100718
    $9.88
    GE15-LR3/8" E A3C - 1000100718×1
  • 281000015494Not stocked
    screw joint×1
  • 291000015491Not stocked
    screw joint×3
  • 301000225910
    $8.70
    WES15L/R 1/2" OMD - 1000225910×1
  • 311000225909
    $11.77
    WES10L/M18X1,5 OMD - 1000225909×1
  • 321000494811Not stocked
    Hose×1
  • 331000220730
    $64.38
    SLHYDR 2SN 12 PN15 0 PN15 115L580,0S - 1000220730×1
  • 341000220547
    $42.22
    SLHYDR 1SN 8,0PN10 0 PN10 90 L1500 S - 1000220547×1
  • 351000220540
    $37.65
    SLHYDR 2SC 8,0PN10 0 PN10 90 L850,0S - 1000220540×1
  • 361000221480
    $23.58
    SLHYDR 2SC 8,0PN10 90 PN10 90 L500,0S270 - 1000221480×1
  • 371000225106
    $95.54
    KIT-SERVICE - 1000225106×1
  • 381000224657
    $86.31
    seal kit gear pump - 1000224657×1
  • 391000112757
    $75.49
    seal kit steering - 1000112757×1
  • 391000170880
    $27.74
    SEAL KIT - 1000170880×1
  • 401000237020
    $62.87
    PIN - 1000237020×1
  • 411000180503
    $49.14
    EV15LOMDA3C - 1000180503×1
