DV100
Despiece de pilot stand · DV100
- 11000310966No la vendemossteering wheel×1
- cover cap - 1000198962×1
- 31000378383No la vendemossteeringstick switch×1
- 41000412654No la vendemosbracket×1
- 51000370676No la vendemossteering column×1
- bracket - 1000403521×1
- CONSOLE - 1000404150×1
- 81000410595No la vendemoscover×1
- 91000405139No la vendemosrubber sleeve×1
- washer 10,5 A2C DIN125 - 1000015432×11
- 111000392495No la vendemosscrew×4
- 121000326519No la vendemosflat head screw×2
- hex screw M10x20-8.8 A2C DIN933 - 1000085411×3
- Ferrit - 1000397270×1
- plate - 1000403889×1
- 161000357535No la vendemoshexagon nut×2
- 171000015430No la vendemosu-washer×2
- 181000015431No la vendemoswasher×7
- SLIDE BEARING - 1000233156×2
- 201000357533No la vendemoshexagon nut×2
- 211000407137No la vendemosnut×1
- screw - 1000389120×2
- Hex Screw M10x25-8.8 A2K-DIN933 - 1000015345×2
- BALL AND SOCKET - 1000015635×1
- 251000409944No la vendemoshandle×1
- hex screw M8x12-8.8 A2C DIN933 - 1000085389×2
- 271000013027No la vendemoswasher×1
- LEVER - 1000405663×1
- 291000410797No la vendemosholder handle×1
- 301000021806No la vendemoshexagon nut×1
- 311000383508No la vendemosrelock lever×1
- 321000410799No la vendemospin×1
- 331000357534No la vendemoshexagon nut×2
- 341000353651No la vendemosrelock lever×1
- 351000389296No la vendemosgas strut×1
- washer A 5,3 A2C DIN125 - 1000094962×7
- pin - 1000351245×2
- hex screw - 1000085377×4
- allen screw M5x16-8.8 A2C DIN912 - 1000085451×3
- cheese head screw - 1000082310×3
- socket head screw M8x12-8.8 A2C DIN912 - 1000085493×2
- 421000350999No la vendemosmetal-rubber buffer×1
- 431000433425No la vendemosbracket×1
- bracket - 1000435149×1
- cheese head screw M10x25-8.8 A2C-DIN912 - 1000085468×4
