GS5.5A GENERATOR

Despiece de Generator Front · GS5.5A

Despiece del Generator Front de una máquina Wacker Neuson GS5.5A, con globos numerados
Pasa por encima de un recuadro para ver la pieza, su precio y su fila. Pincha para marcarla.
  • 15000082801No la vendemos
    Adapter×1
  • 25000083324
    $177.17
    FAN .875 BORE - 5000083324×1
  • 35000083677
    $5.90
    HOUSING-CONNECTOR,6 POLE,PLUG - 5000083677×1
  • 35000083679
    $0.45
    TERMINAL-TAB 14-10 .250 - 5000083679×6
  • 45000025649
    $0.04
    WASHER-LOCK 3/8,MED. - 5000025649×4
  • 55000025554
    $0.14
    SCREW 3/8-16 X 1 GR5,HX.HD. - 5000025554×4
  • 65000084183
    $12.66
    HOUSING-WIRE WAY - 5000084183×1
  • 75000083334
    $1.66
    Bushing - 5000083334×1
  • 85000085742
    $1,916.56
    STATOR-GS5.5/GS6.5 ASSEMBLY - 5000085742×1
  • 95000082856
    $707.87
    ROTOR 5.5-6.5KW - 5000082856×1
  • 105000087289No la vendemos
    Diode×1
  • 105000118869
    $51.37
    KIT-DIODES,1600V,40A - 5000118869×1
  • 115000048467
    $63.66
    BEARING-RADIAL BALL,6203 - 5000048467×1
  • 125000082898No la vendemos
    Bracket×1
  • 135000084064
    $18.78
    ROD-THREADED M6 X 1 X 272 - 5000084064×4
  • 145000010649
    $0.07
    WASHER-LOCK B6 - 5000010649×4
  • 155000010842
    $0.22
    NUT M6 HEX CAP - 5000010842×4
  • 165000085826No la vendemos
    Pan head screw×4
  • 175000083402No la vendemos
    Cover×1
  • 185000082865
    $14.83
    BOLT-HEX 5/16-24 X 6-1/2 - 5000082865×1
  • 195000025648
    $0.29
    WASHER-LOCK 5/16,MED - 5000025648×1
  • 205000083903
    $1.58
    WASHER 5/16 ,FLAT - 5000083903×1
  • 215000085823
    $5.28
    Spacer - 5000085823×4
  • 225000085822No la vendemos
    Baffle×1
  • 235000012613No la vendemos
    Cheese head screw×4
