RD12-90 ROLLER, DOUBLE DRUM, SOLID ROPS
Despiece de Exciter cpl. · RD12-90
- DRUM-VIBRATORY - 5000164064×1
- DRUM COVER P-5000176420 - 5000111053×1
- DRUM COVER P-5000176420 - 5000181479×1
- SHAFT-EXCITER - 5000111051×1
- SHIM-DRUM - 5000114529×1
- COUPLING-FLEXIBLE - 5000078795×1
- SLEEVE-COUPLING - 5000178336×1
- SEAL-SHAFT 45 X 60 X 8,2B - 5000072113×1
- BEARING-CYL.ROLLER,NJ309 - 5000072112×2
- BEARING-RADIAL BALL,6014 - 5000039988×1
- KEY-WOODRUFF 3/16 X 3/4,#90 - 5002009108×1
- RET.RING-EXT 70MMX2.5MM, - 5002004853×1
- SEAL-V RING 80 X 11 X 6.1 - 5000111759×1
- MOTOR-EXCITER,RD12 - 5200001719×1
- KIT-EXCITER MOTOR SEAL,RD12/16 - 5000181468×1
- FITTING-HYD,SAE #6-8 90 ELBOW - 5000111277×2
- O-RING .644 X.087 DURO90 3-908 - 5000080732×1
- O-RING .36 X .07 #6 ORFS 2-012 - 5000080736×1
- NUT-M12,HX.HD,FLG ZN,8.8 - 5000164045×6
- SCREW M10 X 25 HX.HD. - 5000011440×12
- SCREW M10 X 25 SOC.HD. - 5000011535×2
- SCREW M10 X 12 HX.HD. - 5000023405×2
- SCREW-SET M8 X 10 SOC. - 5000012038×2
- WASHER-LOCK A12 - 5000031565×6
- FITTING-GREASE - 5002005948×1
- FITTING-GREASE M6X1,90 DEG. - 5000114393×2
- FITTING-HYD,SAE #4 - 5000111282×1
- O-RING .351 X.072 DURO90 3-904 - 5000080730×1
- O-RING .30 X .07 #4 ORFS 2-011 - 5000112267×1
