VP50H VIBROPLATE
Despiece de Baseplate/Console cpl. · VP50H
- 15000401255No la vendemosBaseplate×1
- 25000401608No la vendemosConsole×1
- 45000400278No la vendemosExciter shaft×1
- 55000400953No la vendemosEnd cap w/seal×1
- 65000400189No la vendemosEnd cap w/hole×1
- 95000400159No la vendemosGuide handle×1
- 115000400124No la vendemosPulley×1
- BEARING-RADIAL BALL,6307-C3 - 5000114484×2
- 145000400238No la vendemosShockmount×4
- SHOCKMOUNT-LOW VIBE - 5000130064×2
- SHOCKMOUNT-M30X20,SPECIAL - 5000105056×2
- PLUG-CAP #1,TAPERED,PLASTC,RED - 5000074985×3
- SCREW M8 X 12 HX.HD. - 5000012360×2
- 265000400297No la vendemosGasket×2
- NUT-LOCK M12X1.75 HEX - 5000010366×2
- WASHER .531X 1.625X.120,FLAT - 5000114766×2
- Washer Lock DIN6796,Zinc Mechanical - 5000407043×6
- 495000011530No la vendemosCheese head screw×1
- SEAL-RING 12 X 18 - 5000013444×1
- SCREW M10 X 20 HX.HD. - 5000012364×4
- Shockmount - 5000130961×1
- WASHER-LOCK - 5000401000×8
- SCREW M6 X 12 SOC.HD. - 5000011554×8
- 2625000130518No la vendemosLifting handle×1
- SPACER-RUBBER - 5000130787×4
- SCREW M10 X 25 HX.HD. - 5000011440×2
