V.Plate DPU 4045Ye
DPU4045YE Fuel Tank Diagram
- 15100000740Not stockedFuel tank cpl.×1
- DRAIN PLUG - 5000213242×1
- GASKET - 5000119882×1
- CAP-ASSY,FUEL TANK - 5000213241×1
- Fuel filter - 5000213243×1
- MOLDING-RUBBER,EDGE PROTECTOR - 5000073747×4
- fuel filter - 5000217895×1
- Bracket - 5000217876×1
- Fixing device - 5000217877×1
- VALVE-FUEL,SHUTOFF - 5000153991×4
- O-RING 15 X 1.3 (S-15) - 5000073751×1
- Bolt - 5000217878×1
- washer - 5000085567×1
- SCREW M6 X 16,HX.FLANGE - 5000073659×2
- SCREW M8 X 45,HEX.FLANGE - 5000085536×1
- NUT-M6 - 5000119722×2
- PIPE ASSY,FUEL OIL - 5000210560×1
- HOSE-FUEL OIL - 5000119891×1
- Clamp - 5000217931×2
- Pipe cpl. - 5100000750×1
- Clamp - 5000073714×1
- 245000217926Not stockedFuel hose×1
- Clamp - 5100000762×1
- Flexible tube - 5000217927×1
- Clamp - 5000217929×1
- 285000217880Not stockedInjection pipe×1
- Support - 5000217881×1
