DPU7060SC VIBROPLATE,DIESEL,SC
DPU7060SC Camshaft cpl. Diagram
- CAMSHAFT COMPL. - 5000204492×1
- Rotary Shaft Seal - 5000204850×1
- SCREW M8X20,SOCKET HD - 5000204716×8
- 55000099476Not stockedCover×1
- GASKET - 5000099475×1
- SCREW M8X16,COUNTERSUNK - 5000204762×2
- GASKET - 5000099477×1
- ROLLER-TAPPET - 5000039965×1
- Screw - 5000034325×1
- WASHER-SPRING A6 - 5000204692×1
- GASKET - 5000099500×1
- SHIM 0.2MM - 5000099501×1
- SHIM 0.4MM - 5000099502×1
- SHIM 1.0MM - 5000099503×1
- PUMP INJECTION 1A65/S2008 - 5000204493×1
- BOLT M8X20,THREADED STUD - 5000204704×1
- SEAL-RING A8X12X1 - 5000204742×2
- SPRING-PRESSURE - 5000204639×1
- seal - 5000204636×1
- VALVE-PRESSURE - 5000204638×1
- pump element - 5000204637×1
- seal - 5000204664×1
- WASHER-SPRING A6 - 5000204696×3
- OIL FILLER - 5000204619×1
- PLUG M30,PLASTIC W/WASHER - 5000034327×1
- Gasket - 5000034326×1
- INSERT-OIL FILLER BASE - 5000048155×1
- NUT M8,HEX - 5000204730×2
- 295000099479Not stockedPushrod guide×1
- GASKET - 5000099478×1
- SCREW M8X20,SOCKET HD - 5000204716×2
- O-RING 32 X 4-70 Sh - 5000037282×1
- ROD-PUSH,INLET - 5000204612×1
- ROD-PUSH,EXHAUST - 5000204613×1
- Tappet - 5000037278×2
- BOLT M8X30,THREADED STUD - 5000204705×1
- SCREW M6X25,SOCKET HD - 5000204714×3
- SCREW M8X25,SOCKET HD - 5000204717×1
