ET18-2

ET18-2 lift arm Diagram

Exploded parts diagram of the lift arm of a Wacker Neuson ET18-2, with numbered balloons
Hover a box for the part, its price and its row below. Click it to select.
  • 11000562060Not stocked
    lift arm×1
  • 21000562061Not stocked
    lift arm×1
  • 31000555309Not stocked
    pin×1
  • 41000307268Not stocked
    pin×1
  • 51000522837Not stocked
    pin×2
  • 61000085322
    $1.31
    hex screw - 1000085322×1
  • 71000357534Not stocked
    hexagon nut×5
  • 81000048174Not stocked
    cheese head screw×2
  • 91000082530
    $1.18
    cheese head screw - 1000082530×2
  • 101000546836Not stocked
    bracket×1
  • 111000546834Not stocked
    bracket×1
  • 121000517278Not stocked
    protection plate×1
  • 131000327876Not stocked
    edge protection×2
  • 141000551450Not stocked
    edge protection×2
  • 151000521587Not stocked
    screw×6
  • 161000288011
    $1.09
    plug M8 - 1000288011×6
  • 171000015475Not stocked
    grease nipple×2
  • 181000546274Not stocked
    pin×1
  • 191000272938
    $5.49
    rubber sleeve oval 23x55/27x59/74x42-5 - 1000272938×3
  • 201000154222
    $4.57
    edge protection - 1000154222×1
