ET20-2

ET20-2 engine hood Diagram

Exploded parts diagram of the engine hood of a Wacker Neuson ET20-2, with numbered balloons
Hover a box for the part, its price and its row below. Click it to select.
  • 11000528142Not stocked
    engine hood×1
  • 21000069463Not stocked
    cylinder lock×1
  • 31000184819
    $14.17
    EZ17 Key without cap - 1000184819×1
  • 41000528729Not stocked
    gas strut×1
  • 51000015416
    $0.71
    DIN985-M8-8-A2C - 1000015416×1
  • 61000550894Not stocked
    plate×2
  • 71000071501Not stocked
    plate×2
  • 81000093886
    $6.41
    adjusting plate - 1000093886×2
  • 91000015448Not stocked
    washer×4
  • 101000357534Not stocked
    hexagon nut×6
  • 111000431384Not stocked
    screw×4
  • 121000521669Not stocked
    bushing×4
  • 131000085320
    $1.13
    hex screw - 1000085320×2
  • 141000328098
    $92.57
    adhesive seal - 1000328098×0.4
  • 151000328098
    $92.57
    adhesive seal - 1000328098×0.4
  • 161000328098
    $92.57
    adhesive seal - 1000328098×0.5
