G70 Generator, Brazil, Premium

G70 Skid/Fuel Tank cpl. Diagram

Exploded parts diagram of the Skid/Fuel Tank cpl. of a Wacker Neuson G70, with numbered balloons
Hover a box for the part, its price and its row below. Click it to select.
  • 45200013710Not stocked
    Frame×1
  • 55200013783Not stocked
    Frame×1
  • 65200014411Not stocked
    Fuel tank×1
  • 75200014218Not stocked
    Cover plate×1
  • 1035200014218Not stocked
    Cover plate×1
  • 3135100018955
    $11.27
    HOSE-FUEL 5/16 X 1330MM - 5100018955×1
  • 3145100013958
    $3.73
    HOSE-FUEL 5/16 X 700MM - 5100013958×1
  • 4205000160596
    $11.12
    FITTING-5/16 BARB X 3/8 F.NPT - 5000160596×2
  • 4255000180571
    $8.60
    FITTING-ELBOW,3/8 NPTFX3/8 NPT - 5000180571×1
  • 4915000178302
    $34.13
    GAUGE-FUEL 349MM P-5000112007 - 5000178302×1
  • 4925000088166
    $5.33
    BUSHING-FUEL GAUGE - 5000088166×1
  • 5105000028707
    $0.67
    CLAMP-THREADED,.21-.63 - 5000028707×2
  • 9005000010895
    $0.58
    NUT-WING M6,STAINLESS STEEL - 5000010895×2
  • 9135000010368
    $0.10
    NUT-LOCK M6 HEX. - 5000010368×2
